Bases
Product Numbers TB1-20, TB1-20 Modified, TB2-20, TB3-20, TB1-17, TB1-17, Modified TB2-17 TB3-17
The Aluminum Breakaway Transformer Bases can be cast in varying sizes and materials. The Steel Fabricated Ballast Housing Base is fabricated per your specifications.
Materials: ASTM A36 Plate, Corten Steel Plate
Finishes: Hot Dip Galvanized Per ASTM A123 AASHTO M111, Primed, Painted, Powder Coated
Accessories Available: Fiberglass Door, Leveling Plates, Warning Stickers, Leveling Washers
SQUARE & OCTAGONAL BASES
Component Products, Inc. manufactures many styles of Pedestal Bases, which can be ordered in the following shapes, materials, and finishes:
SHAPES
Square Octagonal Clam Shell Specials
MATERIALS
Gray Iron - ASTM A48 Class 30 AASHTO M 105
Aluminum - ASTM B179 319.1, 319.2 or ASTM B26 356-T6
Carbon Steel - ASTM A36
FINISHES
NaturalHot Dipped Galvanized Per ASTM A123 AASHTO M 111Painted Per Federal Highway Specification TT489FPowder Coated Per Specification For Color and Thickness CPI PlasticoatAnodizedPrimedWheelabrated FinishEpoxy Finish
All Pedestal Bases come equipped with 18-8 stainless steel bolting and a 1/4-20 tapped hole for a ground lug.The Square Aluminum Base is approved by the FHWA to 1985 AASHTO breakaway requirements.Base accessories include Plastic Doors, Aluminum Doors, Tamper Resistant Latches, Tamper Resistant Bolts, Private Labeled Doors, Ground Lugs, and Set Screws.
PRODUCT NO | DESCRIPTION |
CPI-BAO-1 | OCTAGONAL ALUMINUM BASE - NATURAL |
CPI-BAO-2 | OCTAGONAL ALUMINUM BASE - PAINTED |
CPI-BAS-1 | SQUARE ALUMINUM BASE – NATURAL |
CPI-BAS-2 | SQUARE ALUMINUM MNDOT BASE – GREEN |
CPI-BAS-3 | SQUARE ALUMINUM BASE – PAINTED |
CPI-BCIO-1 | OCTAGONAL CAST IRON BASE – PAINTED |
CPI-BCIO-2 | OCTAGONAL CAST IRON BASE – GALVANIZED |
CPI-BCIO-3 | OCTAGONAL CAST IRON BASE – GALVANIZED CHGO |
CPI-BCIS-1 | SQUARE CAST IRON BASE – PAINTED |
CPI-BCIS-2 | SQUARE CAST IRON BASE – GALVANIZED |
TRANFORMER BASES
The Breakaway Transformer Bases can be cast or fabricated in varying sizes and materials. Aluminum Breakaway Transformer Bases Accessories Available: Plastic Doors Hinged Doors Warning StickersLeveling Washers and Connecting Hardware can be supplied upon request. Steel Fabricated Breakaway Transformer Base The Steel Fabricated Breakaway Base is fabricated per your specifications.
Material: ASTM A36 Plate
Finishes: Hot Dip Galvanized Per ASTM A123 AASHTO M 111 Primed Painted Powder Coated
Accessories Available: Fiberglass Door Leveling Plates Warning Stickers
Material: ASTM A36 Plate
Finishes: Hot Dip Galvanized Per ASTM A123 AASHTO M 111 Primed Painted Powder Coated
Accessories Available: Fiberglass Door Leveling Plates Warning Stickers
PRODUCT NO. | DESCRIPTION | TOP BOLT CIRCLE | BOTTOM BOLT CIRCLE |
CPI-TB-1-17 | ALUMINUM TRANSFORMER BASE | 10 1/2" - 13 1/2" | 13" - 15" |
CPI-TB-1-17 Modified | ALUMINUM TRANSFORMER BASE | 10 1/2" - 13 1/2" | 10 1/2" - 12 15/16" |
CPI-TB-2-17 | ALUMINUM TRANSFORMER BASE | 10" - 12" | 10" - 12" |
CPI-TB-3-17 | ALUMINUM TRANSFORMER BASE | 13" - 15 1/8" | 15" - 17 1/4" |
CPI-TB-1-20 | ALUMINUM TRANSFORMER BASE | 11" - 13" | 13" - 15" |
CPI-TB-1-20 Modified | ALUMINUM TRANSFORMER BASE | 11" - 13" | 10 1/2" - 12 15/16" |
CPI-TB-2-20 | ALUMINUM TRANSFORMER BASE | 10" - 12" | 10" - 12" |
CPI-TB-3-20 | ALUMINUM TRANSFORMER BASE | 13" - 15 1/8" | 15" - 17 1/4" |
CPI-TB-4-20 | ALUMINUM TRANSFORMER BASE | 15" - 18" | 18" - 22" |
CPI-TB-5-9 | ALUMINUM TRANSFORMER BASE | 14 1/2" - 15 1/2" | 14 1/2" - 16 1/4" |
CPI-TB-6-9 | ALUMINUM TRANSFORMER BASE | 10 1/2" - 12" | 10" - 12 3/4" |
CPI-TB-7-9 | ALUMINUM TRANSFORMER BASE | 16" | 15" - 17 1/4" |
CPI-TB-20CC | STL FABRICATED TRANSFORMER BASE | 13" | 15" |
CPI-TB-20NY | STL FABRICATED TRANSFORMER BASE | 12 1/2" | 15" |
